RHINORHIPIDAE

Classification. Polyphaga: Elateriformia.

Distribution. The genus Rhinorhipus is restricted to northern New South Wales and southern Queensland, Australia.

Biogeographic regions: Australian.

Biology. Adult Rhinorhipus may be collected in early Spring on the surfaces of vegetation; immature stages are unknown.

References

Lawrence, J. F. 1988b (1987). Rhinorhipidae, a new beetle family from Australia, with comments on the phylogeny of the Elateriformia. Invertebrate Taxonomy, 2: 1–53.

General appearance. Total length 5–8.5 mm. Ratio of body length to greatest body width 2.71–3.03. Body strongly convex. Sides of body not evenly curved. Body not capable of conglobation (rolling into a ball). Upper surfaces of body clothed with distinct hairs, setae or scales. Vestiture of upper surfaces not including stiff, erect, dark bristles; not including scales or scale-like setae. Upper surfaces of body without deep foveae. Prothorax, metathorax and-or abdomen without extrusible glands. Underside of body without hydrofuge surface(s).

Head. Ratio of head length to its greatest width (excluding eyes) greater than 1. Head width just behind eyes not distinctly greater than prothoracic width. Head moderately to strongly declined; not entirely concealed from above by pronotum; without elongate rostrum; not abruptly constricted posteriorly, or abruptly constricted posteriorly to form neck. Temples absent or not closely adpressed to prothorax; absent, or shorter than length of eye. Transverse occipital ridge or carina absent. Occiput without stridulatory file. Longitudinal axis of head (from occipital foramen to mouth cavity) inclined at an angle of less than 45 degrees. Frontal region strongly deflexed, vertical or inflexed at apex only. Occipital region without median longitudinal groove or line (endocarina). Frontal region without median groove or line (endocarina). Head without ocelli.

Compound eyes present. Eyes strongly protuberant. Vertical diameter of eye less than 2 times horizontal diameter. Eyes finely facetted; without interfacetal setae. Ommatidium of the exocone type. Eye entire. Anterior or mesal edge of eye not or only barely emarginate. Posterior edge of eye not or barely emarginate.

Antennal insertions exposed from above; narrowly separated, or closely approximate or contiguous. Antennae not borne on raised tubercles. Antennal insertions flush with head capsule or raised, not in fossae. Subantennal groove or cavity on head absent or very weakly developed. Frontoclypeal suture absent or incomplete. Clypeus not laterally emarginate. Anterior edge of clypeus or clypeolabrum straight to convex. Mouth cavity anteriorly or anteroventrally oriented. Pregular area without laterally opening cavities. Head ventrally without paired subgenal ridges. Head without anteriorly-projecting genal processes. Gular sutures widely separated or absent. Corporotentorium broad; without median process. Cervical sclerites present.

Antennae. Number of antennomeres 11. Antennae when posteriorly extended reaching beyond middle of prothorax but not middle of elytra, or reaching beyond middle of elytra but not elytral apices. Antennae filiform. Antennomeres 3, 4 or 5 to 10 without or with single rami (uniramose). Antennae at least partly pubescent or with obvious modifications. First antennomere (scape) less than 3 times as long as 2nd (pedicel). Antenna not geniculate; without apical club.

Mouthparts. Labrum concealed beneath clypeus or apparently absent; free, membranous or separated by suture. Major portion of labrum distinctly longer than wide. Apex of labrum strongly convex, narrowly rounded or acute. Labrum mostly membranous or very lightly sclerotized. Mouthparts not forming a piercing or sucking tube. Mandibles present. Mandible moderately elongate. Mandibular apex not or slightly and gradually curved mesally, or moderately to strongly, gradually curved mesally; unidentate, truncate or rounded; subacute, bidentate or multidentate. Dorsal part of mandible without tubercle; with dorsally-opening, setose cavity. Mandible moderately to strongly, more or less evenly sclerotized or pigmented; visible in lateral view. Incisor edge of mandible simple. Mandible without mola; without prostheca. Prostheca absent or without articulated, sclerotized process. Inner basal angle of mandible without pubescent process. Maxilla with distinct galea and lacinia. Maxillary lobe(s) not stylet-like. Apex of galea or maxillary lobe densely setose or spinose; without heavily sclerotized teeth or hooks. Lacinia without hook(s) or spine(s). Apical maxillary palpomere cylindrical to fusiform; at least as wide as or longer than preapical one. Maxillary palp without complex palp organ. Apical labial palpomere cylindrical to fusiform. Ligula deeply emarginate or bilobed.

Prothorax. Ratio of pronotal length to greatest pronotal width 0.93–1.06. Prothorax widest at middle. Sides of prothorax moderately to strongly curved. Prothorax not laterally compressed to form cavities for legs. Sides of prothorax not or slightly explanate. Base of prothorax distinctly narrower than elytral bases. Greatest prothoracic width distinctly narrower than greatest elytral width. Lateral pronotal carinae absent. Lateral portion of prothorax without deep pit. Pronotum without anterolateral callosities. Anterior angles of pronotum absent or not produced forward; absent, right or rounded, not produced. Posterior angles of pronotum absent or broadly rounded, or obtuse or right; not produced and acute. Posterior edge of pronotum more or less straight or evenly rounded; simple; not or vaguely margined. Discal carinae of pronotum absent. Pronotal disc without paired basal impressions, or with paired basal impressions. Pronotum without median longitudinal groove or line. Anterior edge of pronotum simple, without margin. Hypomeron without pit.

Anterior portion of prosternum at midline shorter than prosternal process. Lateral portion of prosternum in front of coxae shorter than mid length of procoxal cavity. Anterior edge of prosternum not produced anteriorly. Prosternum in front of coxae flat to moderately convex. Prosternum in front of coxae without paired lines or carinae. Anterior edge of prosternum without margin; without mesal excavation. Anterolateral or ventrolateral portions of prothorax without cavities or grooves. Prothoracic cavities absent. Prothoracic grooves absent. Prosternal process complete; narrowed apically; flat, concave, or only slightly elevated or curved behind coxae, or strongly elevated and curved dorsally behind coxae; slightly overlapping mesoventrite, or moderately to strongly overlapping mesoventrite. Apex of prosternal process acute or narrowly rounded. Prosternal process without transverse groove. Accessory (mesal) procoxal articulation absent. Ventral portion of prothorax on each side with notosternal suture only. Propleuron not extending to anterior edge of prothorax. Propleuron or pleurotrochantin not extending behind coxa. Procoxae projecting well below prosternum. Procoxa without or with short concealed lateral extension. Procoxal cavity strongly transverse, or slightly transverse. Procoxal cavities at middle narrowly separated. Procoxal cavities externally open; broadly open. Postcoxal projection absent or very short. Procoxal cavities without narrow lateral extensions. Procoxal cavities internally open. Prothoracic trochantin or pleurotrochantin at least partly exposed. Promesothoracic clicking mechanism absent.

Elytra. Elytra present. Ratio of elytral length to greatest elytral width 2.04–2.34. Ratio of elytral length to pronotal length 3.07–3.51. Elytra with more than 5 distinct puncture rows; without scutellary striole. Number elytral puncture rows or striae 12 or more. Sutural stria absent or not deeply impressed near apex. Abdominal tergites exposed by elytra none or apex of 1. Elytral apices meeting or almost meeting at the suture. Elytral suture deflected at or near apex. Elytral apex without internal interlocking tongue. Epipleuron absent or incomplete; not or gradually narrowed. Lateral edge of elytron straight or weakly sinuate.

Pterothorax. Scutellum well developed; abruptly elevated; anteriorly simple; posteriorly broadly rounded or obtusely angulate. Mesoscutum without stridulatory file. Mesoventrite without paired procoxal rests. Paired mesoventral procoxal rests absent, horizontal or slightly oblique. Anterior edge of mesoventrite without prosternal rest, or with median prosternal rest. Mesoventrite not divided by longitudinal groove or discrimen. Anterior edge of mesoventrite at midline on same plane as metaventrite. Mesoventral cavity small and shallow. Mesocoxa conical and projecting. Mesocoxal cavities at middle narrowly separated. Mesocoxae separated by less than shortest diameter of coxal cavity. Mesocoxal cavities circular to slightly transverse; not or slightly oblique. Mesoventrite separated by complete sutures from mesepisterna. Mesepisterna distinctly separated at midline; without deep pockets. Mesepimeron not visible from above. Mesocoxal cavities open laterally; not partly closed by metepisterna. Mesoventral process extending at least to middle of mesocoxal cavity. Mesometaventral junction a complex fitting. Mesoventral and metaventral processes at midline separated by gap, groove, or suture. Accessory (mesal) mesocoxal articulation absent.

Metaventral discrimen or median line short. Paired postcoxal lines of metaventrite absent. Postcoxal lines of metaventrite absent. Metaventrite longer than first abdominal ventrite. Postcoxal pits of metaventrite absent. Metaventrite flat to slightly convex, or moderately to strongly convex. Transverse groove of metaventrite absent. Anterior edge of metaventrite without transverse carina between mesocoxal cavities. Exposed portion of metepisternum short and broad, or moderately elongate. Metacoxae contiguous or narrowly separated; separated by less than longest coxal diameter; extending laterally to meet elytra or sides of body; completely separated from metaventrite by suture. Metacoxal plates weakly developed; not concealing most of basal abdominal ventrite. Metacoxae not greatly enlarged; horizontally oriented. Lateral arms of metendosternite moderately to very long. Metendosternal laminae absent. Ventrolateral processes of metendosternite strongly developed. Anterior process of metendosternite moderately long. Anterior tendons of metendosternite moderately or very close together. Apical portion of metendosternite not or only slightly emarginate.

Hind wing. Hind wing well developed; with normal transverse folds. Radial cell of hind wing well developed; elongate. Inner posterior angle formed at base of radial cell right or obtuse. Radial cell not forming equilateral triangle. Ratio of length of apical area to total wing length less than 0.2, or 0.20–0.35. Apical area of hind wing without veins or sclerotizations, or with one or more vague sclerotizations or pigment patches. Medial bar of hind wing not crossed by fold. Free veins in medial area of hind wing 5 or 6. Oblongum cell of hind wing absent. Medial fleck of hind wing absent; absent or not partly bisected by a vein. Wedge cell of hind wing well developed. Apex of wedge cell of hind wing acute. Anal lobe of hind wing absent. Posterior edge of hind wing without fringe of long hairs.

Legs. Femoral attachment of mid trochanter transverse or slightly oblique. Mesotrochanter not reduced or concealed from below. Metafemur not much wider than mesofemur. Mesotibia not strongly widened. Outer edge of mesotibia with distinct teeth or long spines. Outer subapical edge of mesotibia without antenna cleaner. Preapical surfaces of mesotibia without ridges or combs. Outer apical angle of mesotibia simple or slightly produced, without lobe, teeth or spines. Inner apical angle of mesotibia not or slightly produced, without tooth. Mesotibial spurs glabrous or absent; double. Mesotarsus with 5 distinct tarsomeres (pentamerous). Tarsomeres on hind leg at least as many as on mid leg. Tarsomeres on fore leg at least as many as on mid leg. Mesotarsomere 1 well developed and visible. Preapical mesotarsomeres together longer than apical one. Penultimate mesotarsomere not distinctly shorter than antepenultimate. Ventral mesotarsal lobes absent. Mesotarsal claws paired; subequal in length and similar in form and angle of inclination; serrate, denticulate or pectinate. Appendage on each tarsal claw absent. Mesotarsal claws without setae near base. Mesotarsal empodium present and exposed; with 3 or more setae. Outer edge of protibia simple and rounded to carinate but without lobes or teeth, except at apex. Outer apical angle of protibia simple or slightly produced, without lobe, teeth or spines. Inner subapical edge of protibia without antenna cleaner. Protibial spurs double. Articulations of protibial spurs located in same plane, or located in different planes, one being subapical. Hind legs without swimming hairs. Preapical surfaces of metatibia without ridges or combs. Metatibial articular area not to only moderately expanded, narrowly oval or oblique. Metatibial spurs double; subequal in length and form.

Abdomen. Number of abdominal ventrites 5. Number of basal ventrites connate three. Abdominal sternite 2 apparently absent. First ventrite not completely divided by metacoxae. Suture between ventrites 1 and 2 distinct. Suture between ventrites 2 and 3 distinct. Ventrite 4 articulated with or connate with both 3 and 5. Postcoxal lines on ventrite 1 absent. Ventrite 1 not much longer than 2. Abdominal process acute or narrowly rounded. Ventrite 5 in female without circular depression. Posterior edge of ventrite 5 not crenulate. Last visible tergite and-or sternite (7 or 8) not forming terminal spine. Tergite and sternite 7 separated by membrane or distinct suture. Subapical abdominal luminous organ absent. Ventrites without setose patches or foveae. Functional spiracles on abdominal segment 8 present. Functional spiracles on abdominal segment 7 present. Functional spiracles on abdominal segment 6 present. Functional spiracles on abdominal segment 5 present. 7th abdominal spiracles located in pleural membrane. 6th abdominal spiracles located in pleural membrane. 5th abdominal spiracles located in pleural membrane. Anterior edge of sternite 8 in male without median strut. Pygidium (sclerotized tergite 7 or 8) more or less horizontal. Anterior edge of sternite 9 in male with median strut (spiculum gastrale). Tergite 9 in male deeply emarginate. Tergite 10 in male well developed and free.

Aedeagus trilobate; symmetrical. Anterior edge of tegmen or phallobase without struts. Parameres individually articulated to phallobase or base of penis; not outwardly hooked. Penis without dorsal and ventral lobes. Anterior edge of penis with paired struts.

Illustrations. • Rhinorhipus. Rhinorhipus tamborinensis Lawrence. Locality: Australia. Artist: S. Monteith. Copyright CSIRO. Reference: Lawrence 1988.


The interactive key provides access to the character list, illustrations, full and partial descriptions, diagnostic descriptions, differences and similarities between taxa, lists of taxa exhibiting specified attributes, and summaries of attributes within groups of taxa.

Cite this publication as: ‘Lawrence, J.F., Hastings, A.M., Dallwitz, M.J., Paine, T.A., and Zurcher, E.J. 2000 onwards. Elateriformia (Coleoptera): descriptions, illustrations, identification, and information retrieval for families and subfamilies. Version: 9th October 2005. http://delta-intkey.com’.
