J. F. Lawrence, A. M. Hastings, M. J. Dallwitz, T. A. Paine and E. J. Zurcher

Hyphalinae LIMNICHIDAE

Classification. Polyphaga: Elateriformia.

Distribution. Species of Hyphalus are known from the northeastern coasts of Australia and North Island, New Zealand, Norfolk and Lord Howe Islands, and the Ryukyu Archipelago, Japan.

Biogeographic regions: Australian.

Biology. Hyphalus inhabit marine littoral and intertidal zones, where they may be found on the undersides of rocks which are either submerged moistened by waves at high tide. They apparently feed on blue-green algae.

References

Britton, E. B. 1971. A new intertidal beetle (Coleoptera: Limnichidae) from the Great Barrier Reef. Journal of Entomology (B) 40: 83–91.

Britton, E. B. 1977. Three new intertidal species of Limnichidae (Coleoptera) from New Zealand. Records of the Auckland Museum 14: 81–85.

Satô, M. 1997. Occurrence of a new Hyphalus (Coleoptera, Limnichidae) from the Ryukyu Archipelago, Japan. Elytra, Tokyo 25: 109–112.

General appearance. Total length 1.1–1.6 mm. Ratio of body length to greatest body width 1.65–2.15. Body slightly flattened to moderately convex. Sides of body not evenly curved. Body not capable of conglobation (rolling into a ball). Upper surfaces of body clothed with distinct hairs, setae or scales. Vestiture of upper surfaces not including stiff, erect, dark bristles; not including scales or scale-like setae. Upper surfaces of body without deep foveae. Prothorax, metathorax and-or abdomen without extrusible glands. Underside of body without hydrofuge surface(s).

Head. Ratio of head length to its greatest width (excluding eyes) 1 or less. Head width just behind eyes not distinctly greater than prothoracic width. Head not or slightly declined, or moderately to strongly declined; not entirely concealed from above by pronotum; without elongate rostrum; not abruptly constricted posteriorly. Temples absent or not closely adpressed to prothorax; absent. Transverse occipital ridge or carina absent. Occiput without stridulatory file. Longitudinal axis of head (from occipital foramen to mouth cavity) inclined at an angle of less than 45 degrees. Frontal region not to moderately, gradually declined. Occipital region without median longitudinal groove or line (endocarina). Frontal region without median groove or line (endocarina). Head without ocelli.

Compound eyes present. Eyes not or only slightly protuberant. Vertical diameter of eye less than 2 times horizontal diameter. Eyes coarsely facetted; without interfacetal setae. Ommatidium of the exocone type. Eye entire. Anterior or mesal edge of eye not or only barely emarginate. Posterior edge of eye not or barely emarginate.

Antennal insertions exposed from above, or concealed from above; moderately to widely separated. Antennae not borne on raised tubercles. Subantennal groove or cavity on head absent or very weakly developed. Frontoclypeal suture indistinctly impressed, or distinctly impressed; straight, slightly curved or angulate. Clypeus not laterally emarginate. Anterior edge of clypeus or clypeolabrum straight to convex. Mouth cavity anteriorly or anteroventrally oriented. Pregular area without laterally opening cavities. Head ventrally without paired subgenal ridges. Head without anteriorly-projecting genal processes. Gular sutures widely separated or absent. Corporotentorium narrow; without median process. Cervical sclerites present.

Antennae. Number of antennomeres 11. Antennae when posteriorly extended reaching beyond middle of prothorax but not middle of elytra. Antennae capitate. Antennomeres 3, 4 or 5 to 10 without or with single rami (uniramose). Antennae at least partly pubescent or with obvious modifications. Antennal modifications beginning on antennomere 5 or beyond. First antennomere (scape) less than 3 times as long as 2nd (pedicel). Antenna not geniculate; with weak apical club. Antennal club 3-segmented; not 5-segmented or with 2nd segment subequal to or larger than 1st; loose; not lamellate; not or slightly serrate; not or slightly flattened; not preceded by a cupule.

Mouthparts. Labrum at least partly visible; free, membranous or separated by suture. Major portion of labrum strongly transverse. Apex of labrum subtruncate to slightly convex. Labrum moderately to heavily sclerotized, except at base and-or apex. Mouthparts not forming a piercing or sucking tube. Mandibles present. Mandible short and broad. Mandibular apex moderately to strongly, gradually curved mesally; multidentate or multilobed. Dorsal part of mandible without tubercle; without setose cavity. Incisor edge of mandible with single tooth. Mandible with well developed mola; with well developed prostheca. Prostheca including articulated, sclerotized process. Maxilla with distinct galea and lacinia. Maxillary lobe(s) not stylet-like. Apex of galea or maxillary lobe densely setose or spinose; without heavily sclerotized teeth or hooks. Lacinia without hook(s) or spine(s). Apical maxillary palpomere cylindrical to fusiform; at least as wide as or longer than preapical one. Maxillary palp without complex palp organ. Apical labial palpomere cylindrical to fusiform. Ligula undivided or finely cleft.

Prothorax. Ratio of pronotal length to greatest pronotal width 0.55–0.65. Prothorax widest at middle, or posteriorly. Sides of prothorax moderately to strongly curved. Prothorax not laterally compressed to form cavities for legs. Sides of prothorax not or slightly explanate. Base of prothorax not or slightly narrower than elytral bases. Greatest prothoracic width not or slightly narrower than greatest elytral width. Lateral pronotal carinae complete; simple; visible for their entire lengths from above; with a raised margin or narrow bead. Lateral portion of prothorax without deep pit. Pronotum without anterolateral callosities. Anterior angles of pronotum absent or not produced forward, or distinctly produced forward; absent, right or rounded, not produced, or produced and narrowly rounded or acute. Posterior angles of pronotum obtuse or right; not produced and acute. Posterior edge of pronotum more or less straight or evenly rounded; simple; not or vaguely margined. Discal carinae of pronotum absent. Pronotal disc without paired basal impressions. Pronotum without median longitudinal groove or line. Hypomeron without pit.

Anterior portion of prosternum at midline longer than prosternal process. Lateral portion of prosternum in front of coxae longer than mid length of procoxal cavity. Anterior edge of prosternum distinctly produced forming chin piece. Prosternum in front of coxae flat to moderately convex. Prosternum in front of coxae without paired lines or carinae. Anterior edge of prosternum without mesal excavation. Anterolateral or ventrolateral portions of prothorax without cavities or grooves. Prothoracic cavities absent. Prothoracic grooves absent. Prosternal process complete; parallel-sided; flat, concave, or only slightly elevated or curved behind coxae; moderately to strongly overlapping mesoventrite. Apex of prosternal process broadly rounded, angulate or truncate. Prosternal process without transverse groove. Accessory (mesal) procoxal articulation absent. Ventral portion of prothorax on each side with notosternal suture only. Propleuron not extending to anterior edge of prothorax. Propleuron or pleurotrochantin not extending behind coxa. Procoxae not or slightly projecting below prosternum. Procoxa without or with short concealed lateral extension. Procoxal cavity strongly transverse. Procoxal cavities at middle moderately to widely separated. Procoxal cavities externally open; broadly open. Postcoxal projection absent or very short. Procoxal cavities without narrow lateral extensions. Procoxal cavities internally open. Prothoracic trochantin or pleurotrochantin at least partly exposed. Promesothoracic clicking mechanism absent.

Elytra. Elytra present. Ratio of elytral length to greatest elytral width 1.15–1.65. Ratio of elytral length to pronotal length 2.4–3.1. Elytra apunctate, irregularly punctate, or with 5 or fewer distinct puncture rows or striae; without scutellary striole. Sutural stria absent or not deeply impressed near apex. Abdominal tergites exposed by elytra none or apex of 1. Elytral apices meeting or almost meeting at the suture. Elytral suture not deflected near apex. Elytral apex without internal interlocking tongue. Epipleuron absent or incomplete; not or gradually narrowed. Lateral edge of elytron straight or weakly sinuate.

Pterothorax. Scutellum well developed, or highly reduced; abruptly elevated; anteriorly simple; posteriorly narrowly rounded or acute. Mesoscutum without stridulatory file. Mesoventrite with paired procoxal rests. Paired mesoventral procoxal rests moderately to strongly oblique. Anterior edge of mesoventrite without prosternal rest. Mesoventrite not divided by longitudinal groove or discrimen. Anterior edge of mesoventrite at midline on same plane as metaventrite. Mesoventral cavity moderately large and shallow. Mesocoxa not conical and projecting. Mesocoxal cavities at middle moderately to widely separated. Mesocoxae separated by more than shortest diameter of coxal cavity. Mesocoxal cavities circular to slightly transverse; not or slightly oblique. Mesoventrite separated by complete sutures from mesepisterna, or partly or completely fused to mesepisterna. Mesepisterna distinctly separated at midline; without deep pockets. Mesepimeron not visible from above. Mesocoxal cavities open laterally; not partly closed by metepisterna. Mesoventral process extending at least to middle of mesocoxal cavity. Mesometaventral junction a straight line, or a complex fitting.

Metaventral discrimen or median line moderately to very long. Paired postcoxal lines of metaventrite absent. Postcoxal lines of metaventrite absent. Metaventrite not longer than first abdominal ventrite. Postcoxal pits of metaventrite absent. Metaventrite flat to slightly convex. Transverse groove of metaventrite absent. Anterior edge of metaventrite without transverse carina between mesocoxal cavities. Exposed portion of metepisternum very long and narrow or absent. Metacoxae widely separated; not extending laterally to meet elytra or sides of body; completely separated from metaventrite by suture. Metacoxal plates absent. Metacoxae not greatly enlarged; horizontally oriented. Lateral arms of metendosternite moderately to very long. Metendosternal laminae absent. Ventrolateral processes of metendosternite absent or weakly developed. Anterior process of metendosternite short or absent. Anterior tendons of metendosternite on lateral arms or not apparent. Apical portion of metendosternite not or only slightly emarginate.

Hind wing. Hind wing highly reduced or absent.

Legs. Femoral attachment of mid trochanter transverse or slightly oblique. Mesotrochanter not reduced or concealed from below. Metafemur not much wider than mesofemur. Mesotibia not strongly widened. Outer edge of mesotibia simple, crenulate or denticulate. Outer subapical edge of mesotibia without antenna cleaner. Preapical surfaces of mesotibia without ridges or combs. Outer apical angle of mesotibia simple or slightly produced, without lobe, teeth or spines. Mesotibial spurs glabrous or absent. Mesotarsus with 4 distinct tarsomeres (tetramerous). Tarsomeres on hind leg at least as many as on mid leg. Tarsomeres on fore leg at least as many as on mid leg. Mesotarsomere 1 well developed and visible. Preapical mesotarsomeres together shorter than apical one. Penultimate mesotarsomere not distinctly shorter than antepenultimate. Ventral mesotarsal lobes absent. Mesotarsal claws paired; subequal in length and similar in form and angle of inclination; simple. Appendage on each tarsal claw absent. Mesotarsal claws without setae near base. Mesotarsal empodium absent or with 2 or fewer setae. Inner subapical edge of protibia without antenna cleaner. Hind legs without swimming hairs. Preapical surfaces of metatibia without ridges or combs.

Abdomen. Number of abdominal ventrites 5. Number of basal ventrites connate three. Abdominal sternite 2 apparently absent. First ventrite not completely divided by metacoxae. Suture between ventrites 1 and 2 distinct. Suture between ventrites 2 and 3 distinct. Ventrite 4 articulated with or connate with both 3 and 5. Postcoxal lines on ventrite 1 absent. Ventrite 1 not much longer than 2. Abdominal process truncate or slightly emarginate. Ventrite 5 in female without circular depression. Posterior edge of ventrite 5 not crenulate. Last visible tergite and-or sternite (7 or 8) not forming terminal spine. Subapical abdominal luminous organ absent. Ventrites without setose patches or foveae. Anterior edge of sternite 8 in male with median strut. Anterior edge of sternite 9 in male without median strut. Tergite 9 in male completely fused to tergite 10. Tergite 10 in male completely membranous or fused to tergite 9.

Aedeagus trilobate; symmetrical, or asymmetrical. Anterior edge of tegmen or phallobase without struts. Parameres individually articulated to phallobase or base of penis; not outwardly hooked. Penis without dorsal and ventral lobes. Anterior edge of penis with paired struts.

Illustrations. • Hyphalus. Hyphalus insularis Britton. Locality: Australia. Artist: S. Monteith. Copyright CSIRO. Reference: Britton 1971.


The interactive key provides access to the character list, illustrations, full and partial descriptions, diagnostic descriptions, differences and similarities between taxa, lists of taxa exhibiting specified attributes, and summaries of attributes within groups of taxa.

Cite this publication as: ‘Lawrence, J.F., Hastings, A.M., Dallwitz, M.J., Paine, T.A., and Zurcher, E.J. 2000 onwards. Elateriformia (Coleoptera): descriptions, illustrations, identification, and information retrieval for families and subfamilies. Version: 9th October 2005. http://delta-intkey.com’.
