Elateriformia (Coleoptera)

DELTA Home

J. F. Lawrence, A. M. Hastings, M. J. Dallwitz, T. A. Paine and E. J. Zurcher

Tetralobinae ELATERIDAE

Classification. Polyphaga: Elateriformia.

Distribution. Tetralobine Elateridae occur throughout the warmer parts of the Old World from central and southeastern Africa and Madagascar to Southeast Asia, the East Indies, New Guinea and Australia.

Biogeographic regions: Afrotropical, Oriental, Australian.

Biology. Tetralobinae larvae are associated with the nests of termites. They have been recorded from the nests of Termitidae (Nasutitermes and Macrotermes) and Rhinotermitidae (Coptotermes) in Africa and Australia.

References

Calder, A. A. 1996. Click Beetles: Genera of Australian Elateridae (Coleoptera). Monographs on Invertebrate Taxonomy Vol. 2. CSIRO Publishing, Collingwood, Victoria, x + 401 pp.

Costa, C., S. A. Casari-Chen and S. A. Vanin. 1992. On the larvae of Tetralobini (Coleoptera, Elateridae). Revista Brasileira de Entomologia 36: 879–888.

Costa, C., S. A. Vanin and S. A. Casari-Chen 1994. Cladistic analysis and systematics of the Tetralobini (sensu Stibick), 1979 (Coleoptera, Elateridae, Pyrophorinae). Arquivos de Zoologia 32: 111–157.

Dolin, V. G. 1975. Wing venation of click-beetles (Coleoptera, Elateridae) and its importance for taxonomy of the family. Zoologicheskii Zhurnal 54: 1618–1633 (in Russian).

Dolin, V. G. 1978. Phylogeny of click beetles (Coleoptera, Elateridae). Vestnik Zoologii 1978 (3): 3–12.

Gur'yeva, Ye. L. 1974. Thoracic structure of click beetles (Coleoptera: Elateridae) and the significance of the structural characters for the system of the family. Entomologicheskoye Obozreniye 53: 96–113 (in Russian; translation in Entomological Review, Washington 53: 67–79).

Laurent, L. 1967. La Sous-Famille Tetralobinae (Coleoptera, Elateridae). Bulletin et Annales de la Société Royale d'Entomologique de Belgique 103: 83–109.

Schenkling, S. 1925. Pars 80. Elateridae I. IN: S. Schenkling (ed.), Coleopterorum Catalogus. W. Junk, Berlin, pp. 1–263.

Stibick, J. N. L. 1979. Classification of the Elateridae (Coleoptera). Relationships and classification of the subfamilies and tribes. Pacific Insects 20: 145–186.

General appearance. Total length 20–70 mm. Ratio of body length to greatest body width 2.7–3.4. Body slightly flattened to moderately convex. Sides of body not evenly curved. Body not capable of conglobation (rolling into a ball). Upper surfaces of body glabrous or subglabrous, or clothed with distinct hairs, setae or scales. Vestiture of upper surfaces not including stiff, erect, dark bristles; not including scales or scale-like setae. Upper surfaces of body without deep foveae. Prothorax, metathorax and-or abdomen without extrusible glands. Underside of body without hydrofuge surface(s).

Head. Ratio of head length to its greatest width (excluding eyes) 1 or less. Head width just behind eyes not distinctly greater than prothoracic width. Head not or slightly declined; not entirely concealed from above by pronotum; without elongate rostrum; not abruptly constricted posteriorly. Temples absent or not closely adpressed to prothorax; absent. Transverse occipital ridge or carina absent. Occiput without stridulatory file. Longitudinal axis of head (from occipital foramen to mouth cavity) inclined at an angle of less than 45 degrees. Frontal region strongly deflexed, vertical or inflexed at apex only. Occipital region without median longitudinal groove or line (endocarina), or with median longitudinal groove or line (endocarina). Frontal region without median groove or line (endocarina). Head without ocelli.

Compound eyes present. Eyes strongly protuberant. Vertical diameter of eye less than 2 times horizontal diameter. Eyes finely facetted; without interfacetal setae. Ommatidium of the exocone type. Eye entire. Anterior or mesal edge of eye not or only barely emarginate. Posterior edge of eye not or barely emarginate.

Antennal insertions concealed from above; narrowly separated. Antennae not borne on raised tubercles. Subantennal groove or cavity on head absent or very weakly developed. Frontoclypeal suture absent or incomplete. Clypeus not laterally emarginate. Anterior edge of clypeus or clypeolabrum straight to convex. Mouth cavity anteriorly or anteroventrally oriented. Pregular area without laterally opening cavities. Head ventrally without paired subgenal ridges. Head without anteriorly-projecting genal processes. Gular sutures widely separated or absent. Corporotentorium narrow; without median process. Cervical sclerites present.

Antennae. Number of antennomeres 11, or 12. Antennae when posteriorly extended reaching beyond middle of prothorax but not middle of elytra. Antennae serrate, or pectinate or bipectinate, or flabellate or biflabellate. Antennomeres 3, 4 or 5 to 10 without or with single rami (uniramose). Antennae at least partly pubescent or with obvious modifications. Antennal modifications beginning on antennomere 4. First antennomere (scape) more than 3 times as long as 2nd (pedicel). Antenna not geniculate; without apical club.

Mouthparts. Labrum at least partly visible; free, membranous or separated by suture. Major portion of labrum strongly transverse. Apex of labrum subtruncate to slightly convex. Labrum moderately to heavily sclerotized, except at base and-or apex. Mouthparts not forming a piercing or sucking tube. Mandibles present. Mandible short and broad. Mandibular apex moderately to strongly, gradually curved mesally, or strongly and abruptly curved mesally; unidentate, truncate or rounded. Dorsal part of mandible without tubercle; without setose cavity. Incisor edge of mandible simple. Mandible without mola; with reduced prostheca, or without prostheca. Prostheca absent or without articulated, sclerotized process. Maxilla with distinct galea and lacinia. Maxillary lobe(s) not stylet-like. Apex of galea or maxillary lobe densely setose or spinose; without heavily sclerotized teeth or hooks. Lacinia without hook(s) or spine(s). Apical maxillary palpomere slightly expanded and truncate to subtriangular, or securiform to cultriform; at least as wide as or longer than preapical one. Maxillary palp without complex palp organ. Apical labial palpomere slightly to strongly expanded apically. Ligula undivided or finely cleft, or indistinct or absent.

Prothorax. Ratio of pronotal length to greatest pronotal width 0.66–1.17. Prothorax widest at middle, or posteriorly. Sides of prothorax more or less straight, or straight posteriorly, curved anteriorly, or sinuate. Prothorax not laterally compressed to form cavities for legs. Sides of prothorax not or slightly explanate. Base of prothorax not or slightly narrower than elytral bases. Greatest prothoracic width not or slightly narrower than greatest elytral width. Lateral pronotal carinae complete; simple; visible for their entire lengths from above, or not visible for their entire length from above; without a raised margin, or with a raised margin or narrow bead. Lateral portion of prothorax without deep pit. Pronotum without anterolateral callosities. Anterior angles of pronotum absent or not produced forward, or distinctly produced forward; absent, right or rounded, not produced, or produced and broadly rounded or obtusely angulate. Posterior angles of pronotum obtuse or right, or moderately to strongly acute; not produced and acute, or strongly produced and narrowly acute. Posterior edge of pronotum distinctly sinuate or variously lobed; simple; not or vaguely margined. Discal carinae of pronotum absent, or located on posterior angles only. Pronotal disc without paired basal impressions, or with paired basal impressions. Pronotum without median longitudinal groove or line, or with median longitudinal groove or line. Hypomeron without pit.

Anterior portion of prosternum at midline shorter than prosternal process. Lateral portion of prosternum in front of coxae longer than mid length of procoxal cavity. Anterior edge of prosternum distinctly produced forming chin piece. Prosternum in front of coxae flat to moderately convex, or strongly convex without carina. Prosternum in front of coxae without paired lines or carinae. Anterior edge of prosternum without mesal excavation. Anterolateral or ventrolateral portions of prothorax without cavities or grooves. Prothoracic cavities absent. Prothoracic grooves absent. Prosternal process complete; narrowed apically; flat, concave, or only slightly elevated or curved behind coxae, or slightly to strongly elevated but not curved behind; moderately to strongly overlapping mesoventrite. Apex of prosternal process acute or narrowly rounded. Prosternal process without transverse groove. Accessory (mesal) procoxal articulation absent. Ventral portion of prothorax on each side with notosternal suture only. Propleuron not extending to anterior edge of prothorax. Propleuron or pleurotrochantin not extending behind coxa. Procoxae not or slightly projecting below prosternum. Procoxa without or with short concealed lateral extension. Procoxal cavity circular or longer than wide. Procoxal cavities at middle moderately to widely separated. Procoxal cavities externally open; broadly open, or narrowly open. Postcoxal projection absent or very short, or moderately long but not meeting prosternal process. Procoxal cavities without narrow lateral extensions. Procoxal cavities internally open. Prothoracic trochantin or pleurotrochantin completely concealed or absent. Promesothoracic clicking mechanism present.

Elytra. Elytra present. Ratio of elytral length to greatest elytral width 1.98–2.47. Ratio of elytral length to pronotal length 2–3.55. Elytra apunctate, irregularly punctate, or with 5 or fewer distinct puncture rows or striae, or with more than 5 distinct impressed striae; without scutellary striole. Number elytral puncture rows or striae 10. Sutural stria absent or not deeply impressed near apex. Abdominal tergites exposed by elytra none or apex of 1. Elytral apices meeting or almost meeting at the suture. Elytral suture not deflected near apex. Elytral apex without internal interlocking tongue. Epipleuron absent or incomplete; not or gradually narrowed. Lateral edge of elytron straight or weakly sinuate.

Pterothorax. Scutellum well developed; abruptly elevated; anteriorly simple; posteriorly narrowly rounded or acute, or broadly rounded or obtusely angulate. Mesoscutum without stridulatory file. Mesoventrite without paired procoxal rests, or with paired procoxal rests. Paired mesoventral procoxal rests absent, horizontal or slightly oblique, or vertical. Anterior edge of mesoventrite without prosternal rest. Mesoventrite not divided by longitudinal groove or discrimen. Anterior edge of mesoventrite at midline on same plane as metaventrite. Mesoventral cavity moderately to very large and deep. Mesocoxa not conical and projecting. Mesocoxal cavities at middle moderately to widely separated. Mesocoxae separated by less than shortest diameter of coxal cavity. Mesocoxal cavities circular to slightly transverse; not or slightly oblique. Mesoventrite separated by complete sutures from mesepisterna. Mesepisterna distinctly separated at midline; without deep pockets. Mesepimeron not visible from above. Mesocoxal cavities open laterally; not partly closed by metepisterna. Mesoventral process absent or not extending to middle of mesocoxal cavity. Mesometaventral junction an anteriorly curved, angulate or acute line.

Metaventral discrimen or median line moderately to very long. Paired postcoxal lines of metaventrite absent. Postcoxal lines of metaventrite absent. Metaventrite longer than first abdominal ventrite. Postcoxal pits of metaventrite absent. Metaventrite flat to slightly convex. Transverse groove of metaventrite absent. Anterior edge of metaventrite without transverse carina between mesocoxal cavities. Exposed portion of metepisternum moderately elongate, or very long and narrow or absent. Metacoxae contiguous or narrowly separated; extending laterally to meet elytra or sides of body; completely separated from metaventrite by suture. Metacoxal plates well developed mesally, weak laterally; not concealing most of basal abdominal ventrite. Metacoxae not greatly enlarged; horizontally oriented. Lateral arms of metendosternite short or absent. Metendosternal laminae absent. Ventrolateral processes of metendosternite absent or weakly developed. Anterior process of metendosternite moderately long. Anterior tendons of metendosternite moderately or very close together. Apical portion of metendosternite not or only slightly emarginate.

Hind wing. Hind wing well developed; with normal transverse folds. Radial cell of hind wing well developed; elongate. Inner posterior angle formed at base of radial cell right or obtuse. Radial cell not forming equilateral triangle. Ratio of length of apical area to total wing length less than 0.2. Medial bar of hind wing not crossed by fold. Free veins in medial area of hind wing 5 or 6. Oblongum cell of hind wing absent. Medial fleck of hind wing absent; absent or not partly bisected by a vein. Wedge cell of hind wing absent. Anal lobe of hind wing absent. Posterior edge of hind wing without fringe of long hairs.

Legs. Femoral attachment of mid trochanter transverse or slightly oblique. Mesotrochanter not reduced or concealed from below. Metafemur not much wider than mesofemur. Mesotibia not strongly widened. Outer edge of mesotibia simple, crenulate or denticulate. Outer subapical edge of mesotibia without antenna cleaner. Preapical surfaces of mesotibia without ridges or combs. Outer apical angle of mesotibia simple or slightly produced, without lobe, teeth or spines. Mesotibial spurs glabrous or absent. Mesotarsus with 5 distinct tarsomeres (pentamerous). Tarsomeres on hind leg at least as many as on mid leg. Tarsomeres on fore leg at least as many as on mid leg. Mesotarsomere 1 well developed and visible. Preapical mesotarsomeres together longer than apical one. Penultimate mesotarsomere not distinctly shorter than antepenultimate. Ventral mesotarsal lobes on more than one tarsomere. Mesotarsal claws paired; subequal in length and similar in form and angle of inclination; simple. Appendage on each tarsal claw absent. Mesotarsal claws without setae near base. Mesotarsal empodium present and exposed; with 3 or more setae. Inner subapical edge of protibia without antenna cleaner. Hind legs without swimming hairs. Preapical surfaces of metatibia without ridges or combs.

Abdomen. Number of abdominal ventrites 5. Number of basal ventrites connate four. Abdominal sternite 2 apparently absent. First ventrite not completely divided by metacoxae. Suture between ventrites 1 and 2 distinct. Suture between ventrites 2 and 3 distinct. Ventrite 4 articulated with or connate with both 3 and 5. Postcoxal lines on ventrite 1 absent. Ventrite 1 not much longer than 2. Abdominal process acute or narrowly rounded. Ventrite 5 in female without circular depression. Posterior edge of ventrite 5 not crenulate. Last visible tergite and-or sternite (7 or 8) not forming terminal spine. Subapical abdominal luminous organ absent. Ventrites without setose patches or foveae. Functional spiracles on abdominal segment 8 present. Anterior edge of sternite 8 in male without median strut. Anterior edge of sternite 9 in male without median strut. Tergite 9 in male deeply emarginate, or completely fused to tergite 10. Tergite 10 in male well developed and free, or partly fused to tergite 9, or completely membranous or fused to tergite 9.

Aedeagus trilobate; symmetrical. Anterior edge of tegmen or phallobase without struts. Parameres individually articulated to phallobase or base of penis; not outwardly hooked. Penis without dorsal and ventral lobes. Anterior edge of penis with paired struts.

Illustrations. • Pseudotetralobus. Pseudotetralobus sp. Locality: Australia. Photo: D. McClenaghan. Copyright CSIRO.


The interactive key provides access to the character list, illustrations, full and partial descriptions, diagnostic descriptions, differences and similarities between taxa, lists of taxa exhibiting specified attributes, and summaries of attributes within groups of taxa.

Cite this publication as: ‘Lawrence, J.F., Hastings, A.M., Dallwitz, M.J., Paine, T.A., and Zurcher, E.J. 2000 onwards. Elateriformia (Coleoptera): descriptions, illustrations, identification, and information retrieval for families and subfamilies. Version: 9th October 2005. http://delta-intkey.com’.
