Elateriformia (Coleoptera)

DELTA Home

J. F. Lawrence, A. M. Hastings, M. J. Dallwitz, T. A. Paine and E. J. Zurcher

Semiotus Semiotinae ELATERIDAE

Classification. Polyphaga: Elateriformia.

Distribution. Species of Semiotus occur throughout tropical America from Mexico to Brazil and northern Argentina.

Biogeographic regions: Neotropical.

Biology. Semiotus larvae are usually found in moist, sappy areas under bark, and have been observed feeding on fly larvae.

References

Calder, A. A., J. F. Lawrence and J. W. H. Trueman 1993. Austrelater, gen. nov. (Coleoptera: Elateridae), with a description of the larva and comments on elaterid relationships. Invertebrate Taxonomy 7: 1349–1394.

Costa, C. 1972. Sobre a larva y pupa de Semiotus ligneus Linnaeus, 1767 (Elateridae, Semiotinae). Papéis Avulsos de Zoologia 26: 51–53.

Dolin, V. G. 1975. Wing venation of click-beetles (Coleoptera, Elateridae) and its importance for taxonomy of the family. Zoologicheskii Zhurnal 54: 1618–1633 (in Russian).

Golbach, R. 1970. Semiotinae, nueva subfamilia de Elateridae (Col.). Acta Zoologica Lilloana 25: 319–322.

Gur'yeva, Ye. L. 1974. Thoracic structure of click beetles (Coleoptera: Elateridae) and the significance of the structural characters for the system of the family. Entomologicheskoye Obozreniye 53: 96–113 (in Russian; translation in Entomological Review, Washington 53: 67–79).

Laurent, L. 1961. Sur la suture méso-mêtasternale chez les Elateridae (Coleoptera). Bulletin de la Société Royale des Sciences de Liège 30: 68–71.

Schenkling, S. 1925. Pars 80. Elateridae I. IN: S. Schenkling (ed.), Coleopterorum Catalogus. W. Junk, Berlin, pp. 1–263.

Schwarz, O. 1906–1907. Coleoptera Fam. Elateridae. IN: P. Wytsman (ed.), Genera Insectorum. Fascicule 46. P. Wytsman, Brussels, 370 pp., 6 pls.

Stibick, J. N. L. 1979. Classification of the Elateridae (Coleoptera). Relationships and classification of the subfamilies and tribes. Pacific Insects 20: 145–186.

General appearance. Total length 22–40 mm. Ratio of body length to greatest body width 3.33–4.25. Body slightly flattened to moderately convex. Sides of body not evenly curved. Body not capable of conglobation (rolling into a ball). Upper surfaces of body glabrous or subglabrous. Vestiture of upper surfaces not including stiff, erect, dark bristles; not including scales or scale-like setae. Upper surfaces of body without deep foveae. Prothorax, metathorax and-or abdomen without extrusible glands. Underside of body without hydrofuge surface(s).

Head. Ratio of head length to its greatest width (excluding eyes) greater than 1. Head width just behind eyes not distinctly greater than prothoracic width. Head not or slightly declined; not entirely concealed from above by pronotum; without elongate rostrum; not abruptly constricted posteriorly. Temples absent or not closely adpressed to prothorax; absent. Transverse occipital ridge or carina absent. Occiput without stridulatory file. Longitudinal axis of head (from occipital foramen to mouth cavity) inclined at an angle of less than 45 degrees, or inclined at an angle of 45 to 90 degrees. Frontal region not to moderately, gradually declined. Occipital region without median longitudinal groove or line (endocarina). Frontal region without median groove or line (endocarina). Head without ocelli.

Compound eyes present. Eyes strongly protuberant. Vertical diameter of eye less than 2 times horizontal diameter. Eyes finely facetted; without interfacetal setae. Ommatidium of the exocone type. Eye entire. Anterior or mesal edge of eye not or only barely emarginate. Posterior edge of eye not or barely emarginate.

Antennal insertions concealed from above; moderately to widely separated. Antennae not borne on raised tubercles. Subantennal groove or cavity on head absent or very weakly developed. Frontoclypeal suture absent or incomplete. Clypeus not laterally emarginate. Anterior edge of clypeus or clypeolabrum straight to convex. Mouth cavity anteriorly or anteroventrally oriented. Pregular area without laterally opening cavities. Head ventrally with paired subgenal ridges. Head without anteriorly-projecting genal processes. Gular sutures widely separated or absent. Corporotentorium narrow; without median process. Cervical sclerites present.

Antennae. Number of antennomeres 11. Antennae when posteriorly extended reaching beyond middle of prothorax but not middle of elytra. Antennae serrate. Antennomeres 3, 4 or 5 to 10 without or with single rami (uniramose). Antennae at least partly pubescent or with obvious modifications. Antennal modifications beginning on antennomere 3 (rarely 2). First antennomere (scape) less than 3 times as long as 2nd (pedicel), or more than 3 times as long as 2nd (pedicel). Antenna not geniculate; without apical club.

Mouthparts. Labrum at least partly visible; free, membranous or separated by suture. Major portion of labrum strongly transverse. Apex of labrum subtruncate to slightly convex. Labrum moderately to heavily sclerotized, except at base and-or apex. Mouthparts not forming a piercing or sucking tube. Mandibles present. Mandible short and broad, or moderately elongate. Mandibular apex moderately to strongly, gradually curved mesally, or strongly and abruptly curved mesally; bidentate or bilobed. Dorsal part of mandible without tubercle; without setose cavity. Incisor edge of mandible simple. Mandible without mola; with reduced prostheca. Prostheca absent or without articulated, sclerotized process. Maxilla with distinct galea and lacinia. Maxillary lobe(s) not stylet-like. Apex of galea or maxillary lobe densely setose or spinose; without heavily sclerotized teeth or hooks. Lacinia without hook(s) or spine(s). Apical maxillary palpomere slightly expanded and truncate to subtriangular, or securiform to cultriform; at least as wide as or longer than preapical one. Maxillary palp without complex palp organ. Apical labial palpomere slightly to strongly expanded apically. Ligula undivided or finely cleft.

Prothorax. Ratio of pronotal length to greatest pronotal width 1.1–1.35. Prothorax widest posteriorly. Sides of prothorax more or less straight, or sinuate. Prothorax not laterally compressed to form cavities for legs. Sides of prothorax not or slightly explanate. Base of prothorax not or slightly narrower than elytral bases. Greatest prothoracic width not or slightly narrower than greatest elytral width. Lateral pronotal carinae complete; simple; visible for their entire lengths from above; without a raised margin, or with a raised margin or narrow bead. Lateral portion of prothorax without deep pit. Pronotum without anterolateral callosities. Anterior angles of pronotum distinctly produced forward; produced and broadly rounded or obtusely angulate. Posterior angles of pronotum moderately to strongly acute; strongly produced and narrowly acute. Posterior edge of pronotum distinctly sinuate or variously lobed; simple; not or vaguely margined. Discal carinae of pronotum absent. Pronotal disc without paired basal impressions, or with paired basal impressions. Pronotum without median longitudinal groove or line, or with median longitudinal groove or line. Hypomeron without pit.

Anterior portion of prosternum at midline longer than prosternal process. Lateral portion of prosternum in front of coxae longer than mid length of procoxal cavity. Anterior edge of prosternum distinctly produced forming chin piece. Prosternum in front of coxae flat to moderately convex, or strongly convex without carina. Prosternum in front of coxae without paired lines or carinae. Anterior edge of prosternum without mesal excavation. Anterolateral or ventrolateral portions of prothorax without cavities or grooves. Prothoracic cavities absent. Prothoracic grooves absent. Prosternal process complete; narrowed apically; slightly to strongly elevated but not curved behind; moderately to strongly overlapping mesoventrite, or concealing most or all of mesoventrite. Apex of prosternal process acute or narrowly rounded. Prosternal process without transverse groove. Accessory (mesal) procoxal articulation absent. Ventral portion of prothorax on each side with notosternal suture only. Propleuron not extending to anterior edge of prothorax. Propleuron or pleurotrochantin not extending behind coxa. Procoxae not or slightly projecting below prosternum. Procoxa without or with short concealed lateral extension. Procoxal cavity circular or longer than wide. Procoxal cavities at middle moderately to widely separated. Procoxal cavities externally open; broadly open. Postcoxal projection absent or very short. Procoxal cavities without narrow lateral extensions. Procoxal cavities internally open. Prothoracic trochantin or pleurotrochantin completely concealed or absent. Promesothoracic clicking mechanism present.

Elytra. Elytra present. Ratio of elytral length to greatest elytral width 2.33–3.1. Ratio of elytral length to pronotal length 2.3–2.7. Elytra with more than 5 distinct puncture rows; without scutellary striole. Number elytral puncture rows or striae 9. Sutural stria absent or not deeply impressed near apex. Abdominal tergites exposed by elytra none or apex of 1. Elytral apices independently rounded or acute and separated by broad gap. Elytral suture not deflected near apex. Elytral apex without internal interlocking tongue. Epipleuron absent or incomplete; not or gradually narrowed, or abruptly narrowed or excavated. Lateral edge of elytron straight or weakly sinuate.

Pterothorax. Scutellum well developed; abruptly elevated; anteriorly simple, or notched; posteriorly broadly rounded or obtusely angulate, or truncate. Mesoscutum without stridulatory file. Mesoventrite with paired procoxal rests. Paired mesoventral procoxal rests absent, horizontal or slightly oblique. Anterior edge of mesoventrite without prosternal rest. Mesoventrite not divided by longitudinal groove or discrimen. Anterior edge of mesoventrite at midline on different plane than metaventrite. Mesoventral cavity moderately to very large and deep. Mesocoxa not conical and projecting. Mesocoxal cavities at middle moderately to widely separated. Mesocoxae separated by more than shortest diameter of coxal cavity. Mesocoxal cavities circular to slightly transverse; not or slightly oblique. Mesoventrite separated by complete sutures from mesepisterna. Mesepisterna distinctly separated at midline; without deep pockets. Mesepimeron not visible from above. Mesocoxal cavities open laterally; not partly closed by metepisterna. Mesoventral process extending at least to middle of mesocoxal cavity. Mesometaventral junction absent due to fusion. Mesoventral and metaventral processes at midline solidly fused or separated at most by weakly impressed line.

Metaventral discrimen or median line moderately to very long. Paired postcoxal lines of metaventrite absent. Postcoxal lines of metaventrite absent. Metaventrite longer than first abdominal ventrite. Postcoxal pits of metaventrite absent. Metaventrite flat to slightly convex. Transverse groove of metaventrite absent. Anterior edge of metaventrite without transverse carina between mesocoxal cavities. Exposed portion of metepisternum very long and narrow or absent. Metacoxae contiguous or narrowly separated; extending laterally to meet elytra or sides of body; completely separated from metaventrite by suture. Metacoxal plates well developed mesally, weak laterally; not concealing most of basal abdominal ventrite. Metacoxae not greatly enlarged; horizontally oriented. Lateral arms of metendosternite moderately to very long. Metendosternal laminae absent. Ventrolateral processes of metendosternite absent or weakly developed. Anterior process of metendosternite moderately long. Anterior tendons of metendosternite moderately or very close together. Apical portion of metendosternite not or only slightly emarginate.

Hind wing. Hind wing well developed; with normal transverse folds. Radial cell of hind wing well developed; elongate. Inner posterior angle formed at base of radial cell right or obtuse. Radial cell not forming equilateral triangle. Ratio of length of apical area to total wing length less than 0.2. Medial bar of hind wing not crossed by fold. Free veins in medial area of hind wing 5 or 6. Oblongum cell of hind wing absent. Medial fleck of hind wing absent; absent or not partly bisected by a vein. Wedge cell of hind wing well developed. Anal lobe of hind wing absent. Posterior edge of hind wing without fringe of long hairs.

Legs. Femoral attachment of mid trochanter transverse or slightly oblique. Mesotrochanter not reduced or concealed from below. Metafemur not much wider than mesofemur. Mesotibia not strongly widened. Outer edge of mesotibia simple, crenulate or denticulate. Outer subapical edge of mesotibia without antenna cleaner. Preapical surfaces of mesotibia without ridges or combs. Outer apical angle of mesotibia simple or slightly produced, without lobe, teeth or spines. Mesotibial spurs glabrous or absent. Mesotarsus with 5 distinct tarsomeres (pentamerous). Tarsomeres on hind leg at least as many as on mid leg. Tarsomeres on fore leg at least as many as on mid leg. Mesotarsomere 1 well developed and visible. Preapical mesotarsomeres together longer than apical one. Penultimate mesotarsomere not distinctly shorter than antepenultimate. Ventral mesotarsal lobes on more than one tarsomere. Mesotarsal claws paired; subequal in length and similar in form and angle of inclination; simple. Appendage on each tarsal claw absent. Mesotarsal claws without setae near base. Mesotarsal empodium absent or with 2 or fewer setae. Inner subapical edge of protibia without antenna cleaner. Hind legs without swimming hairs. Preapical surfaces of metatibia without ridges or combs.

Abdomen. Number of abdominal ventrites 5. Number of basal ventrites connate four. Abdominal sternite 2 apparently absent. First ventrite not completely divided by metacoxae. Suture between ventrites 1 and 2 distinct. Suture between ventrites 2 and 3 distinct. Ventrite 4 articulated with or connate with both 3 and 5. Postcoxal lines on ventrite 1 absent. Ventrite 1 not much longer than 2. Abdominal process acute or narrowly rounded. Ventrite 5 in female without circular depression. Posterior edge of ventrite 5 not crenulate. Last visible tergite and-or sternite (7 or 8) not forming terminal spine. Subapical abdominal luminous organ absent. Ventrites without setose patches or foveae. Functional spiracles on abdominal segment 8 present. Anterior edge of sternite 8 in male without median strut. Anterior edge of sternite 9 in male without median strut. Tergite 9 in male deeply emarginate. Tergite 10 in male well developed and free.

Aedeagus trilobate; symmetrical. Anterior edge of tegmen or phallobase without struts. Parameres individually articulated to phallobase or base of penis; not outwardly hooked. Penis without dorsal and ventral lobes. Anterior edge of penis with paired struts.

Illustrations. • Semiotus. Semiotus jansoni Candèze. Locality: South America. Reference: Schwarz 1907. Courtesy of Institut Royal des Sciences Naturelles de Belgique.


The interactive key provides access to the character list, illustrations, full and partial descriptions, diagnostic descriptions, differences and similarities between taxa, lists of taxa exhibiting specified attributes, and summaries of attributes within groups of taxa.

Cite this publication as: ‘Lawrence, J.F., Hastings, A.M., Dallwitz, M.J., Paine, T.A., and Zurcher, E.J. 2000 onwards. Elateriformia (Coleoptera): descriptions, illustrations, identification, and information retrieval for families and subfamilies. Version: 9th October 2005. http://delta-intkey.com’.
